Description
226800185 GB/T297-1994 BEARING 32028
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 231201484 车架装配 Frame assembly 1
2 231201485 前轮装配 Front Wheel Fitting 1
3 231201486 后轮装配 Back Wheel Fitting 1
4 231201487 传动系统 Driving system 1
5 231201488 XMR083.05 动力系统 Engine system 1
6 231201471 操纵系统 control system 1
7 231201489 电气系统 Electric system 1
8 231201490 液压系统 Hydraulic system 1
9 231201491 机罩 Engine Cover 1
10 231201475 洒水系统 Sprinkling system 1
11 231201476 刮泥板 SCRAPE BLADE 1
12 231201492 油漆与标记 paint and decals 1
1 231201495 上平台 Top frame 1
2 231201674 下车架 down frame 1
3 231201451 护套 Jacket 1
4 231201541 斜拉杆 Rod 1
5 805000043 螺栓 M10×30 Bolt 2 GB/T 5783-2000
6 805300014 垫圈 10 Washer 11 GB/T93-1987
7 805200048 螺母 M10 Nut 3 GB/T6170-2000
8 231201540 起吊架 Suspend clamp 1
9 805000099 螺栓M12×60 Bolt 2 GB/T5783-2000
10 805300018 垫圈12 washer 12 14 GB/T93-1987
11 231201538 检修盖 Repair 2
12 805000033 螺栓M8×16 Bolt 12 GB/T5783-2000
13 805300010 垫圈 8 Washer 12
14 805000518 螺栓M10X60 Bolt 1
15 231201450 护套 Jacket 1
16 231201708 摇摆架 sway stand 1
17 805000048 螺栓M12X35 Bolt 4 GB/T5783-2000
18 231200140 减震块 Shock absorber 4
19 805200049 螺母 M12 Nut 6 GB/T6170-2000
20 231200190 锲块 Block 2
21 231200141 左掩车体座 Left cover block 1
22 805000715 螺栓 M12×25 Bolt 4 GB/T 5783-2000
23 805000014 螺栓 Bolt 2
24 231200145 右掩车体座 Right cover block 1
25 231200143 扶手销 Pin 1
26 801100336 黄油嘴M10X1 Grease Nipple 1 JB/T7940.1-1995
27 231200144 弹簧 Spring 1
28 805200069 螺母 M12 Nut 1 GB/T 6172.1-2000
29 805300020 垫圈12 Washer 1 GB/T97.1-2002
30 231200163 拉手 Handle 1
31 805600334 销B20X45 Pin 1 GB/T882-1986
32 231201496 挡块 Plate 2
33 805000727 螺栓M10X25 Bolt 4 GB/T5783-2000
34 800349673 回转支撑 Rotating support bearings 1 010.20.163.03
35 805000444 螺栓 M14×65 Bolt M14×65 10 GB/T5783-2000
36 805338329 垫圈 20 Lock Washer 22
37 805100450 螺栓M14X35 Bolt 12 GB/T70.1-2000
38 803164185 O型圈 O-ring 2 GB/T3452.1-2005
39 800511316 轴承6310-2RS Bearing 2 GB/T276-1994
40 805000616 螺栓 M8×12 Bolt 1 GB/T5783-2000
41 805300069 垫圈 8 Washer 8 1
42 231200149 闷盖 Cover 1
43 805400045 挡圈 110 RING 2 GB/T893.1-1986
44 231201553 偏心轴 Eccentricity shaft 1
45 231200147 防尘圈 Prevent dust cover 1
46 231200146 透盖 Cover 1
47 231201539 弯板 Plate 2
48 231200257 压板 Plate 2
49 231200258 隔尘板 Prevent dust cover 1
50 231200162 皮带轮 Belt roller 1
51 805701143 键C8X25 Key 1 GB/T1096-1979
52 231200259 压板 Plate 1
53 805000714 螺栓 M10×20 Blot 1 GB/T5783-2000
54 231200242 调整垫 Washer 2
55 231200252 调整垫 Washer 1
56 230500932 橡胶护套 Molding jacket 1
57 805000062 螺栓 M10×35 Bolt 4 GB/T 5783-2000
