Description

803538043 GGD03-1 Working Lamp

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 860118977 门锁 Latch 1
2 860118978 左门焊接总成 The left door 1
3 860118979 内扶手 Interior armrest 2
4 805000017 螺栓 M8×25 bolt 8 GB/T5783-2000
5 227000341 左限位固定板 Left restraint Fixing Plane 1
6 ▲225600323-09010306 驾驶室焊接总成 Welding assembly of the cab 1
7 227000344 收放机连接板 Plate 1
8 805300029 垫圈 6 Washer 6 1 GB/T97.1-2002
9 805300030 垫圈 6 Washer 6 1 GB/T93-1987
10 805001895 螺栓M6×16 Bolt 1
11 227000342 限位活动板 Restraint moveable plane 2
12 805000089 螺栓 M8X35 Bolt 4 GB/T 5783-2000
13 227000350 平垫 Flat plate 10
14 805201502 螺母 M8 4
15 227000340 右限位固定板 Right restraint Fixing Plane 1
16 860118980 右门焊接总成 The right door 1
17 801100340 油杯M6×1 grease cup 1
18 227000170 轴 Shaft 4
19 227000171 套 Bushing 8
20 227000174 垫 Plate 4
21 805200080 螺母M10 Nut 4
22 805101945 螺钉M5×16 Screw 4
23 805300119 垫圈5 Washer 4 GB/T 97.1-2002
24 802101285 拉手 Knob 2
25 227000354 M8螺帽 Screw cap 28
26 805000018 螺栓 M8×20) Elbow 12
27 805300010 垫圈 8 Washer 12
28 805300069 垫圈 8 Washer 8 12
29 860118981 外扶手 Exterior armrest 2
30 ▲227000247-080330 胶条L=9.5m Strip 1
1 860118147 顶内饰 Inner decoration of the canopy 1
2 860118148 左门内饰 Inner decoration of the left door 1
3 227000346 锁支架盖板 Cover board of the lock support 2
4 805100140 自攻螺钉ST4.2×16 Self-tapping sponge 6
5 860117966 隔热棉 Thermal insulation sponge 1
6 860117967 隔热棉 Thermal insulation sponge 1
7 860117971 隔热棉 Thermal insulation sponge 1
8 860117970 隔热棉 Thermal insulation sponge 1
9 860117969 隔热棉 Thermal insulation sponge 1
10 860117968 隔热棉 Thermal insulation sponge 1
11 860118149 右门内饰 Inner decoration of the right door 1
12 ▲227000247-080212 驾驶室电气 Cab electrical appliances 1
13 802101289 室内后视镜 Interior rear-view mirror 1
14 805101946 螺钉ST4.2×25 Screw 1
