Description

612600180175 stop solenoid WEICHAI

YD480-01005 缸盖螺栓 Cylinder head bolt 10
2 Y480G-01002 气缸盖垫片 Cylinder head gasket 1
3 GB/T62-2004 蝶形螺母 M6 Butterfly Nut M6 1
4 GB/T848-2002 垫圈 6-140HV Washer 6-140HV 1
5 Y480G-01201 呼吸器盖 Respirator Cover 1
6 Y480G-01203 滤网 Filter Gauze 1
7 Y480G-01202 呼吸器隔板 Respirator Partition 1
8 Y480G-01210 呼吸器焊接件 Respirator Weldment 1
9 GB/T5783-2000 螺栓 M8×20 Bolt M8×20 31
10 GB/T848-2002 垫圈 8-140HV Washer 8-140HV 54
11 GB/T93-1987 垫圈 8 Washer 8 54
12 Y480G-01011 呼吸器垫片 Breathing component gasket 1
13 Y480G-01703 放油螺塞 Oil rain screw plug 1
14 Y480G-01704 垫圈 Washer 1
15 Y480G-01701 油底壳 Oil sump 1
16 Y480G-01024 凸轮轴前衬套 Front camshaft bush 1
17 Y380Q -37 -01025 凸轮轴中衬套 Middle camshaft bush 1

18 Y480G-01026 凸轮轴后衬套 Rear camshaft bush 1
19 GB/T5783-2000 螺栓 M8×70 Bolt M8×70 1
20 GB/T5783-2000 螺栓 M8×65 Bolt M8×65 7
21 GB/T5783-2000 螺栓 M8×55 Bolt M8×55 4
22 Y480G-01109 碗形塞片(Φ50) Bowl patch(Φ50) 1
23 GB/T119.1-2000 销 B8×20 Pin B8×20 2
24 Y480G-01108 堵塞 Stopper 4
25 GB/T5783-2000 螺栓 M8×25 Bolt M8×25 7
26 Y480G-01012 侧盖(Ⅰ) Side cover(Ⅰ) 1
27 Y480G-01023 侧盖(Ⅰ)垫片 Side cover gasket(Ⅰ) 1
28 Y480G-01003 气缸套 Cylinder sleeve 4
29 YD480-01111a 机体 Engine body 1
30 Y480G-01012 侧盖(Ⅱ) Side cover(Ⅱ) 1
31 Y480G-01023 侧盖(Ⅱ)垫片 Side cover gasket(Ⅱ) 1
32 Y480G-01102 定位套 Locating sleeve 2
33 Y480G-01009 飞轮壳垫片 Flywheel housing gasket 1
34 Y480G-01101 塞片 Inspection cover 1
35 Y480G-01103 碗形塞片(φ25) Bowl-shaped plug piece(φ25) 4
36 YD480-01400 机油尺部件 Oil level dipstick 1

37 YD480-01500 油尺导管焊接件 Dipstick sleeve weldment 1
38 GB/T119.1-2000 销 B10×20 Pin B10×20 2
39 GB/T848-2002 垫圈 10-140HV Washer 10-140HV 14
40 GB/T93-1987 垫圈 10 Washer 10 14
41 Y480G-01300 放水开关组件 Water release drain unit 1
42 Y480G-01021 机油压力传感器接管 Connecting pipe for oil pressure sensor 1
43 Y480G-01500 压力表用传感器部件 Water release drain unit 1
44 Y480G-01004 机油滤清器垫片 Oil filter gasket 1
45 GB/T5782-2000 螺栓 M8×50 Bolt M8×50 1
46 Y480G-01007 曲轴止推片(上) Upper thrust piece of crankshaft 2
47 Y480G-01008 曲轴止推片(下) Lower thrust piece of crankshaft 2
48 Y480G-01015 主轴瓦上瓦 Main bearing halfshell(upper) 5
49 Y480G-01016 主轴瓦下瓦 Main bearing halfshell(lower) 5
50 Y480G-01107a 堵塞 Stopper 1
51 Y480G-01106a 闷头(Ⅱ) Stopper(Ⅱ) 4
52 Y480G-01113 后主轴承盖 Rear main bearing cap 1
53 Y480G-01109 碗形塞片(φ44) Bowl-shaped plug piece(φ44) 1
54 GB/T5782-2000 螺栓 M8×30 Bolt M8×30 3
55 Y480G-01115 主轴承盖螺栓 Main bearing bolt 10

56 Y480G-01018 油底壳垫片 Oil sump 1
57 Y480G-01112 主轴承盖 Main bearing cap 4
58 Y480G-01105b 闷头(Ⅰ) Stopper(Ⅰ) 4
59 Y480G-01010 飞轮壳 Flywheel housing 1
60 HG4-692-67 骨架式橡胶油封 PG80×100×12 Oil seal PG80×100×12 1
61 GB/T818-2000 螺钉 M6×12 Stud M6×12 2
62 GB/T93-1987 垫圈 6 Washer 6 2
63 Y480G-01019 盖板 Cover plate 1
64 GB/T5782-2000 螺栓 M10×30 Bolt M10×30 14
