802141597 JF-JZ-20X ENGINE HOOD
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲226500375-040601 钢球 20mm KL.3 DIN5401 Ball 1
2 ▲226500375-040602 压力弹簧 2.5×16.95×57.2 Spring 1
3 ▲226500375-040603 阀套 Cover 1
4 ▲226500375-040604 阀芯 Core 1
5 ▲226500375-040605 压力弹簧 2.8×16.84×87.1 Spring 1
6 ▲226500375-040606 垫圈 14×28 DIN125 200HV Washer 1
1 ▲226500375-040701 连接外壳 Cover 1
2 ▲226500375-040702 螺栓 M10×35 Bolt 12
3 ▲226500375-040703 弹性园柱销 10×28 Pin 2
4 ▲226500375-040704 弹性园柱销 6×28 PIn 2
5 ▲226500375-040705 膜片组件 Membranaceous 1
6 ▲226500375-040706 膜片组件 Membranaceous 1
7 ▲226500375-040707 螺栓 M10×18 Bolt 4
8 ▲226500375-040708 螺栓 M10×25 Bolt 12
9 ▲226500375-040709 罩法兰 Flange 1
10 ▲226500375-040710 罩法兰 Flange 1
11 ▲226500375-040711 垫圈 Washer 1
12 ▲226500375-040712 O形圈 25×3 O-ring 1
13 ▲226500375-040713 孔用挡圈 30×1.2 Snap ring 1
14 ▲226500375-040714 螺栓 M10×50 Bolt 2
1 ▲226500375-040801 轴 Shaft 1
2 ▲226500375-040802 O型圈 O-ring 1
3 ▲226500375-040803 搭扣密封环 Seal ring 3
4 ▲226500375-040804 螺柱 M8×18 DIN939 8,8 Bolt 3
5 ▲226500375-040805 螺母 M8 DIN934 8 Nut 3
6 ▲226500375-040806 调整垫片 Washer 1
7 ▲226500375-040807 承磨垫 Washer 1
8 ▲226500375-040808 止动垫片 Washer 1
9 ▲226500375-040809 齿轮 Gear 1
10 ▲226500375-040810 承磨垫 Washer 1
11 ▲226500375-040811 滚柱轴承 Bearing 1
12 ▲226500375-040812 承压板 Plate 2
13 ▲226500375-040813 活塞 Piston 2
14 ▲226500375-040814 异形密封环 Seal ring 2
15 ▲226500375-040815 止动片 Plate 1
16 ▲226500375-040816 止动片 Plate 1
17 ▲226500375-040817 异形密封环 Seal ring 2
18 ▲226500375-040818 压力弹簧 Spring 2
19 ▲226500375-040819 导向环 Ring 4
20 ▲226500375-040820 挡圈 Snap ring 2
21 ▲226500375-040821 导向环 Ring 2
22 ▲226500375-040822 滚针轴承 F3526 35×42×26 Bearing 1
23 ▲226500375-040823 弹性挡圈 Snap ring 1
24 ▲226500375-040824 滚针轴承 F4026 40×47×26 Bearing 1
25 ▲226500375-040825 弹性挡圈 Snap ring 1
26 ▲226500375-040826 弹性挡圈 Snap ring 2
27 ▲226500375-040827 承磨垫 Washer 1
28 ▲226500375-040828 齿轮 Gear 1
29 ▲226500375-040829 孔用挡圈 75×2.5 DIN472 Snap ring 2
30 ▲226500375-040830 调整垫片 Washer 1
31 ▲226500375-040831 滚针组 45×53×27.8 Bearing 1
32 ▲226500375-040832 挡圈 Snap ring 1
33 ▲226500375-040833 钢球 10mm Ball 2
34 ▲226500375-040834 圆柱销 Pin 2
35 ▲226500375-040835 螺钉 M12×20 Bolt 2
36 ▲226500375-040836 球轴承 6009 MAC3 45×75×16 Bearing 1
37 ▲226500375-040837 离合器外壳 Cover 1
38 ▲226500375-040838 外摩擦片 Attrition plate 12
39 ▲226500375-040839 内摩擦片 Attrition plate 9
40 ▲226500375-040840 内摩擦片 Attrition plate 1
41 ▲226500375-040841 内摩擦片 Attrition plate 1
42 ▲226500375-040842 外摩擦片 Attrition plate 8
43 ▲226500375-040843 内摩擦片 Attrition plate 4
44 ▲226500375-040844 内摩擦片 Attrition plate 2
45 ▲226500375-040845 内摩擦片 Attrition plate 1
