Description

802141811 JF-SHD-01 ENGINE HOOD LAMP

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲226500375-040901 轴 Shaft 1
2 ▲226500375-040902 O型圈 O-ring 1
3 ▲226500375-040903 搭扣密封环 Seal 3
4 ▲226500375-040904 螺柱 M8×18 DIN939 8,8 Bolt 3
5 ▲226500375-040905 螺母 M8 DIN934 8 Nut 3
6 ▲226500375-040906 调整垫片 Washer 1
7 ▲226500375-040907 承磨垫 Washer 1
8 ▲226500375-040908 止动垫片 Washer 1
9 ▲226500375-040909 齿轮 Gear 1
10 ▲226500375-040910 承磨垫 Washer 1
11 ▲226500375-040911 滚柱轴承 F-2034 Bearing 1
12 ▲226500375-040912 承压板 Plate 2
13 ▲226500375-040913 活塞 Piston 2
14 ▲226500375-040914 异形密封环 Seal ring 2
15 ▲226500375-040915 止动片 Plate 1
16 ▲226500375-040916 止动片 Plate 1
17 ▲226500375-040917 异形密封环 Seal ring 2
18 ▲226500375-040918 压力弹簧 Spring 2
19 ▲226500375-040919 导向环 Ring 4
20 ▲226500375-040920 挡圈 Snap ring 2
21 ▲226500375-040921 导向环 Ring 2
22 ▲226500375-040922 滚针轴承 F3526 35×42×26 Bearing 1
23 ▲226500375-040923 弹性挡圈 Snap ring 1
24 ▲226500375-040924 滚针轴承 F4026 40×47×26 Bearing 1
25 ▲226500375-040925 弹性挡圈 Snap ring 1
26 ▲226500375-040926 弹性挡圈 Snap ring 2
27 ▲226500375-040927 承磨垫 Washer 1
28 ▲226500375-040928 齿轮 Gear 1
29 ▲226500375-040929 滚柱轴承 K45×75×32,2/24,4 Bearing 1
30 ▲226500375-040930 挡圈 Snap ring 3
31 ▲226500375-040931 离合器外壳 Cover 1
32 ▲226500375-040932 外摩擦片 Attrition plate 9
33 ▲226500375-040933 内摩擦片 Attrition plate 4
34 ▲226500375-040934 内摩擦片 Attrition plate 3
35 ▲226500375-040935 内摩擦片 Attrition plate 1
36 ▲226500375-040936 外摩擦片 Attrition plate 8
37 ▲226500375-040937 内摩擦片 Attrition plate 4
38 ▲226500375-040938 内摩擦片 Attrition plate 2
39 ▲226500375-040939 内摩擦片 Attrition plate 1
1 ▲226500375-041001 阀体 Valve 1
2 ▲226500375-041002 锁片 Lock 1
3 ▲226500375-041003 弹簧 Spring 1
4 ▲226500375-041004 阀芯 Core 1
5 ▲226500375-041005 弹簧 Spring 1
6 ▲226500375-041006 隔套 Cover 1
7 ▲226500375-041007 垫片 Washer 6
8 ▲226500375-041008 衬套 Cover 1
9 ▲226500375-041009 阀芯 Core 1
10 ▲226500375-041010 弹簧 Spring 1
11 ▲226500375-041011 挡销 Pin 1
12 ▲226500375-041012 O形圈 O-ring 1
13 ▲226500375-041013 阀芯 Core 1
14 ▲226500375-041014 弹簧 Spring 1
15 ▲226500375-041015 阀芯 Core 1
16 ▲226500375-041016 挡销 Pin 1
17 ▲226500375-041017 固定板 Plate 1
18 ▲226500375-041018 阀芯 Core 1
19 ▲226500375-041019 弹簧 Spring 1
20 ▲226500375-041020 弹簧 Spring 1
21 ▲226500375-041021 阀芯 Core 1
22 ▲226500375-041022 挡销 Pin 1
23 ▲226500375-041023 O形圈 O-ring 1
24 ▲226500375-041024 锁片 Lock 1
25 ▲226500375-041025 挡销 Pin 1
26 ▲226500375-041026 弹簧 Spring 1
27 ▲226500375-041027 阀芯 Core 1
28 ▲226500375-041028 弹簧 Spring 1
29 ▲226500375-041029 阀芯 Core 1
30 ▲226500375-041030 挡销 Pin 1
31 ▲226500375-041031 O形圈 O-ring 1
32 ▲226500375-041032 盖 Cover 1
33 ▲226500375-041033 纸垫 Washer 1
34 ▲226500375-041034 六角头螺栓 M5×18 DIN933 8.8 Bolt 11
35 ▲226500375-041035 电磁阀 Valve 4
36 ▲226500375-041036 内六角螺栓 M5×12 DIN912 8.8 Bolt 8
37 ▲226500375-041037 弹簧垫圈 5 DIN7980 Washer 8
38 ▲226500375-041038 电缆组件 Cable 1
39 ▲226500375-041039 开槽螺钉 M4×12 DIN84 4.8 Bolt 4
40 ▲226500375-041040 鞍型弹性垫圈 Washer 4
41 ▲226500375-041041 电磁阀罩壳 Vavle cover 1
42 ▲226500375-041042 O形圈 O-ring 1
43 ▲226500375-041043 弓夹 Clamp 1
44 ▲226500375-041044 螺塞 M10×1 DIN910 Plug 6
45 ▲226500375-041045 紫铜垫圈 A10×13.5 DIN7603 Washer 6
