Description
803164963 XGHL5-700×10 FILTER XCMG
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲228500184-040501 制动盘 Brake disc 12 734.07.004.02
2 ▲228500184-040502 制动盘 Brake disc 12 112.07.610.02
3 ▲228500184-040503 弹簧 Spring 6 176.07.006.01
4 ▲228500184-040504 调节螺栓 Adjusting bolt 6 176.07.019.01
5 ▲228500184-040505 透气塞 Vent 4 020.01.1538
6 ▲228500184-040506 止动垫圈 Locking washer 4 011.13.1227
7 ▲228500184-040507 弹性垫圈 Spring 4 176.07.047.01
8 ▲228500184-040508 螺母 Nut 4 006.05.0684
9 ▲228500184-040509 活塞 Piston 2 176.07.045.01
10 ▲228500184-040510 O形圈 O-ring 4 001.05.1647
11 ▲228500184-040511 O形圈 O-ring 4 001.05.0050
12 ▲228500184-040512 中间制动盘 Intermediate brake disc 2 176.07.044.04
13 ▲228500184-040513 环 Ring 2 176.07.048.01
14 ▲228500184-040514 小齿轮 Pinion 2 176.07.021.01
15 ▲228500184-040515 止动片 Locking plate 2 176.07.023.02
16 ▲228500184-040516 六角螺栓 Hexagon bolt 2 016.01.0794
17 ▲228500184-040517 O形圈 O-ring 2 001.05.1526
18 ▲228500184-040518 螺钉 Cylinder bolt 4 016.04.0427
19 ▲228500184-040519 螺栓 Bolt 4 176.07.022.03
1 ▲228500184-040601 螺钉 Cylinder bolt 4 016.01.0847
2 ▲228500184-040602 盖 Cover 1 193.14.002.03
3 ▲228500184-040603 齿轮 Gear 1 193.14.004.03
4 ▲228500184-040604 球轴承 Ball bearing 1 005.01.0124
5 ▲228500184-040605 机壳 Housing 1 193.14.001.02
6 ▲228500184-040606 透气塞 Vent 1 702.01.003.03
7 ▲228500184-040607 螺钉 Cylinder bolt 10 016.04.0429
8 ▲228500184-040608 齿轮 Gear 1 193.14.003.01
9 ▲228500184-040609 柱头螺栓 Cylinder bolt 4 016.04.0432
10 ▲228500184-040610 弹性垫圈 Spring washer 10 011.01.0223
11 ▲228500184-040611 六角螺栓 Hexagon bolt 10 016.03.0897
12 ▲228500184-040612 磁性螺塞 Magnet plug 1 819.01.610.01
13 ▲228500184-040613 螺塞 Plug 1 808.01.017.01
14 ▲228500184-040614 螺柱 Stud 4 017.02.0460
15 ▲228500184-040615 螺母 Nut 4 006.03.1197
16 ▲228500184-040616 弹性垫圈 Spring washer 4 011.01.0225
17 ▲228500184-040617 套管 Spacer 4 819.15.020.01
18 ▲228500184-040618 板 Sheet 1 723.14.053.03
19 ▲228500184-040619 O形圈 O-ring 1 001.05.2606
20 ▲228500184-040620 垫圈 Washer 2 011.07.2763
21 ▲228500184-040621 接头 Adaptor 1 307.14.006.01
22 ▲228500184-040622 接头 Adaptor 1 307.14.005.01
