Description

400201188 LW161.1.2 MUFFLER BRACKET

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲226800286-040601 制动盘 Brake Disc 1
2 ▲226800286-040602 放气嘴保护罩 Cap 4
3 ▲226800286-040603 销轴 Pin 8
4 ▲226800286-040604 放气嘴 Bleeder Valve 4
5 ▲226800286-040605 O型圈75×3.1 O-Ring 4
6 ▲226800286-040606 夹钳体 Caliper 2
7 ▲226800286-040607 螺栓M20*60 Bolt 12
8 ▲226800286-040608 垫圈 Washer 12
9 ▲226800286-040609 螺母M10 Nut 8
10 ▲226800286-040610 螺栓M10*35 Bolt 8
11 ▲226800286-040611 螺栓M20*55 Bolt 6
12 ▲226800286-040612 垫圈18 Washer 16
13 ▲226800286-040613 钢球 Steel ball 4
14 ▲226800286-040614 垫圈10 Washer 16
15 ▲226800286-040615 螺栓M18*40 Bolt 16
16 ▲226800286-040616 圆柱销 Column pin 8
17 ▲226800286-040617 螺栓M10*35 Bolt 16
18 ▲226800286-040618 孔塞 Plug 2
19 ▲226800286-040619 摩擦片 Friction pad 4
20 ▲226800286-040620 摩擦垫块底板 Backing plate 4
21 ▲226800286-040621 矩形密封圈 Seal 8
22 ▲226800286-040622 活塞 Piston 8
23 ▲226800286-040623 防尘圈 Dust proof ring 8
24 ▲226800286-040624 进油分泵盖 Cover 2
25 ▲226800286-040625 封油分泵盖 Cover 2
1 800302278 变速箱 Gearbox 1
2 805002045 螺栓 M22×55 Bolt 2 GB/T5783-2000
3 805300084 螺栓M20×50 Bolt 2
4 805300058 垫圈 22 Washer 22 2 GB/T93-1987
5 226800244 左支架 Bracket 1
6 805300023 垫圈 20 Washer 20 4 GB/T93-1987
7 805000144 螺栓M20×45 bolt 4 GB/T 5783-2000
8 226800247 右支架 Bracket 1
9 805000375 螺栓M14×55 Bolt 4 GB/T5783-2000
10 805300033 垫圈 14 WASHER 4 GB/T93-1987
11 801902782 减振器 Shock absorber 2
12 805300144 垫圈14 WASHER 4
13 805200067 螺母M14 Nut 4
