Description

860131169 LW188 CAB LAMP

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 860118423 轮边减速器总成 Planetaryassembly 2
2 860118424 桥壳总成 Axle Housing Assembly 1 Ⅰ
2 860118425 桥壳总成 Axle Housing Assembly 1 Ⅱ\Ⅲ
3 ▲226800286-040203 螺栓M14*1.5*45 Bolt 2
4 ▲226800286-040204 螺栓M14*1.5*35 Bolt 10
5 ▲226800286-040205 螺栓M14*1.5*60 Bolt 2
6 ▲226800286-040206 定位销 Pin 2
7 ▲226800286-040207 弹垫14 Washer 14
8 860118382 主减速器总成(哈) Carrier Assembly 1
8 860113705 主减速器总成 Carrier Assembly 1
9 860115206 制动器总成 Brake Assembly. 4
10 860110239 球面螺母及螺栓 Spherical Nut 4 驱动桥附件
11 ▲226800286-040211 轮辋螺母M22*1.5 Rim Nut 24
12 860115457 通气塞Z1/8 PlugZ1/8 1
13 ▲226800286-040213 组合垫24 Compound seal washer 2
14 ▲226800286-040214 螺塞M24×1.5 Plug 2
15 860117598 半轴 Axle shaft 2
16 ▲226800286-040216 标牌 Decal 1
17 ▲226800286-040217 铆钉Φ3*6 Rivet 4
1 ▲226800286-040501 行星轮轴 Planet pin 4
2 ▲226800286-040502 隔套 Spacer 4
3 ▲226800286-040503 太阳轮 Sun Gear 1
4 ▲226800286-040504 挡圈（轴用）50 Circlip 1
5 ▲226800286-040505 行星轮 Planet gear 4
6 ▲226800286-040506 行星轮垫片 Washer 8
7 ▲226800286-040507 螺塞M24*1.5 Plug 1
8 ▲226800286-040508 组合密封垫24 Compound Seal washer 1
9 ▲226800286-040509 调整支柱 Adjusting column 1
10 ▲226800286-040510 限位块 Block 1
11 ▲226800286-040511 螺栓M12*1.25*25 Bolt 7
12 ▲226800286-040512 垫圈12 Washer 7
13 ▲226800286-040513 螺钉M10*30 Screw 3
14 ▲226800286-040514 垫圈85 Washer 1
15 ▲226800286-040515 螺母 Nut 2
16 ▲226800286-040516 隔套 Spacer 1
17 ▲226800286-040517 锥套 Sleeve 1
18 ▲226800286-040518 内齿轮 Ring Gear 1
19 ▲226800286-040519 轴承2007126E Bearing 1
20 ▲226800286-040520 轴承2007122E Bearing 1
21 ▲226800286-040521 油封座 Oil Seal Cage 1
22 ▲226800286-040522 轮毂 Hub 1
23 ▲226800286-040523 油封BA150*180*15 Oil Seal 1
24 ▲226800286-040524 油封FA150*180*15 Oil Seal 1
25 ▲226800286-040525 挡油板 Ring 1
26 ▲226800286-040526 滚针6×30 Roller 216
27 ▲226800286-040527 组合密封垫12 Compound Seal washer 1
28 ▲226800286-040528 螺塞M12*1.25*9 Plug 1
29 ▲226800286-040529 垫圈10 Washer 1
