Description

860141423 DY242-LW160KV Voltage gauge

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲800302345-011001 加油管组件(L=800) Filler tube assembly(L=800) 1
2 ▲800302345-011002 纸垫 δ=0,8 Pad of paper δ=0,8 2
3 ▲800302345-011003 螺栓 M8×50 DIN931 8,8 Bolt M8×50 DIN931 8,8 2
4 ▲800302345-011004 油标尺组件(A/B/D/F=838/798/53/10) Dipstick assembly(A/B/D/F=838/798/53/10) 1
5 ▲800302345-011005 挡板 Bezel 1
1 ▲800302345-011101 地面泵齿轮Z=51 Ground pump gear Z=51 1
2 ▲800302345-011102 轴用挡圈 19×1,2 DIN471 Shaft Collar 19×1,2 DIN471 2
3 ▲800302345-011103 泵(柱塞) q=32cm^3/r Pump（Plunger) q=32cm^3/r 1
4 ▲800302345-011104 螺柱 M8×170 DIN939 10,9 Stud M8×170 DIN939 10,9 4
5 ▲800302345-011105 厌氧胶 NR,241/50ML 按A/R3 ZFN 164 Anaerobic NR,241/50M According A/R3 ZFN 164 4
6 ▲800302345-011106 螺母 M8 DIN934 10 Screw nut M8 DIN934 10 4
7 ▲800302345-011107 调整垫片20×28×0.5/0.3/1/0.2 DIN988 Adjusting washer20×28×0.5/0.3/1/0.2 DIN988 1
1 ▲800302345-011201 旋装滤油器 Spin-on oil filter 1
1 ▲800302345-011301 轴(151) Axis(151) 1
2 ▲800302345-011302 O型圈 49×3 ZFN744 O-ring 49×3 ZFN744 1
3 ▲800302345-011303 搭扣密封环 38/35,2×2,0 Hasp sealing ring 38/35,2×2,0 3
4 ▲800302345-011304 螺柱 M8×18 DIN939 8,8 Stud M8×18 DIN939 8,8 3
5 ▲800302345-011305 厌氧胶NR,241/50ML 按A/R3 ZFN 164 Anaerobic NR,241/50ML AccordingA/R3 ZFN 164 3
6 ▲800302345-011306 螺母 M8 DIN934 8 Screw nut M8 DIN934 8 3
7 ▲800302345-011307 调整垫片 Adjusting washer 1
8 ▲800302345-011308 齿轮(KV) Z/mn/α=44/4,0/20° Gear(KV) Z/mn/α=44/4,0/20° 1
9 ▲800302345-011309 承磨垫DUP Order of the sanding pad DUP 1
10 ▲800302345-011310 滚柱轴承F-2034 (35×81,5×20,4) Roller bearing F-2034 (35×81,5×20,4) 1
11 ▲800302345-011311 承压板 Bearing plate 2
12 ▲800302345-011312 活塞 Piston 2
13 ▲800302345-011313 异形密封环 φ150×5,72×2,5 Profiled sealing ring φ150×5,72×2,5 2
14 ▲800302345-011314 止动片 Stopper piece 1
15 ▲800302345-011315 止动片 Stopper piece 1
16 ▲800302345-011316 异形密封环 φ60×5,72×2,5 Profiled sealing ring φ60×5,72×2,5 2
17 ▲800302345-011317 压力弹簧 6,5×66,07×48,6 Pressure spring 6,5×66,07×48,6 2
18 ▲800302345-011318 导向环 Guide ring 4
19 ▲800302345-011319 挡圈 AV55 FA.ORBIS Collar AV55 FA.ORBIS 2
20 ▲800302345-011320 导向环 Guide ring 2
21 ▲800302345-011321 滚针轴承 F3526 35×42×26 FA.Torrington Needle Roller Bearing F3526 35×42×26 FA.Torrington 1
22 ▲800302345-011322 弹性挡圈 NT-01364 Circlip NT-01364 1
23 ▲800302345-011323 滚针轴承 F4026 40×47×26 FA.Torrington Needle Roller Bearing F4026 40×47×26 FA.Torrington 1
24 ▲800302345-011324 弹性挡圈 NT-01363 Circlip NT-01363 1
25 ▲800302345-011325 弹性挡圈 Circlip 2
26 ▲800302345-011326 承磨垫DUP Order of the sanding pad DUP 1
27 ▲800302345-011327 齿轮(K1) Z/mn/α=26/4,5/24° Gear(K1) Z/mn/α=26/4,5/24° 1
28 ▲800302345-011328 孔用挡圈 75×2,5 DIN472 Hole Collar 75×2,5 DIN472 1
29 ▲800302345-011329 调整垫片 DIN988 Adjusting washer DIN988 1
30 ▲800302345-011330 滚针组 45×53×27,8 Needle Group 45×53×27,8 1
31 ▲800302345-011331 挡圈 Collar 1
32 ▲800302345-011332 钢球 10mm G20 DIN5401 Ball 10mm G20 DIN5401 2
33 ▲800302345-011333 圆柱销 Cylindrical pin 2
34 ▲800302345-011334 螺钉 M12×20 DIN915 8,8 Screw M12×20 DIN915 8,8 2
35 ▲800302345-011335 球轴承 6009MAC3 45×75×16 Ball Bearing 6009MAC3 45×75×16 1
36 ▲800302345-011336 离合器外壳 Clutch housing 1
37 ▲800302345-011337 Kv离合器 NR,10 间隙 2,2-2,4mm Kv Clutch NR,10 Clearance 2,2-2,4mm 1
38 ▲800302345-011338 外摩擦片 D=177,5 S=2,0 Outer friction plate D=177,5 S=2,0 9
39 ▲800302345-011339 内摩擦片S=2,0 Inner friction plate S=2,0 8
40 ▲800302345-011340 内摩擦片S=2,5 Inner friction plate S=2,5 5
41 ▲800302345-011341 内摩擦片S=2,0/2,5 Inner friction plate S=2,0/2,5 2
42 ▲800302345-011342 K1离合器 NR,20 间隙 2,0-2,9mm K1 Clutch NR,20 Clearance 2,0-2,9mm 1
43 ▲800302345-011343 外摩擦片 D=177,5 S=2,0 Outer friction plate D=177,5 S=2,0 8
