803164013 JB/T8406-2001 HOSE B32×880
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 800302412 驱动桥 Axle assembly 1
2 805001986 螺栓 M22×280 10.9 Bolt M22×280 10.9 8 GB/T5782-2000
3 225701074 销 Pin 4
4 805300084 螺栓M20×50 Bolt 8
5 805300058 垫圈 22 Washer 22 8 GB/T93-1987
6 805301388 垫圈 20 Washer 20 8 GB/T849-1988
7 805001985 螺栓M20×175 Bolt 8
8 800302327 链条 10B-1X72 Chain 2
9 225701075 板 Board 2
10 225701076 支座 Support seat 2
11 805301406 垫圈20 Washer 8
12 805101789 螺钉 M20×70 10.9 Screw M20 × 70 10.9 8
1 ▲225701587-0403 主减速器总成 Carrier assembly 1 82627500
2 ▲225701587-040202 磁性螺塞ZG 3/4” Plug 1 79900330
3 ▲225701587-0404 轮边总成 Planetary assembly 2 83627000
4 ▲225701587-040204 半轴 Axle shaft 2 80627001
5 ▲225701587-040205 垫圈14 Washer 14 52020005
6 ▲225701587-040206 桥壳 总成 Housing assembly 1 81627100
7 ▲225701587-040207 组合密封垫24 Compound seal 2 53200005
8 ▲225701587-040208 螺塞M24X1.5 Plug 2 75500197
9 ▲225701587-040209 螺栓M14X1.5X35 Bolt 10 50012017
10 ▲225701587-040210 螺栓M14X1.5X45 Bolt 2 50012031
11 ▲225701587-040211 螺栓M14X1.5X60 Bolt 2 50011012
12 ▲225701587-040212 通气塞Z1/8” Plug 1 56100001
13 ▲225701587-040213 销A12X20 Pin 3 51270005
1 ▲225701587-040301 主传动齿轮副 Pinion 1 82180501
2 ▲225701587-040302 螺母 M14x1.5 Nut 12 75501992
3 ▲225701587-040303 螺栓 M14X1.5X50 Bolt 12 75500003
4 ▲225701587-040304 轴承 Bearing 1 54500006
5 ▲225701587-040305 轴承 Bearing 2 54500003
6 ▲225701587-040306 铁丝φ1X100 Thread of iron 2 56000005
7 ▲225701587-040307 调整螺母 Adjusting nut 2 75200118
8 ▲225701587-040308 止推螺栓组件 Bolt 1 79600094
9 ▲225701587-040309 螺母 M27x2 M27x2 Nut 1 51070004
10 ▲225701587-040310 油封FB80X100X10 Oil seal 1 53100003
11 ▲225701587-040311 油封B80X100X10 Oil seal 1 53100010
12 ▲225701587-040312 垫圈 12 Washer 1 52020004
13 ▲225701587-040313 螺栓M12x1.5×55 Bolt 1 50011008
14 ▲225701587-040314 螺栓M14x1.5×55 Bolt 7 50011011
15 ▲225701587-040315 垫圈14 Washer 7 52020005
16 ▲225701587-040316 锁紧螺母 Lock nut 1 75500269
17 ▲225701587-040317 垫圈 Washer 1 75500231
18 ▲225701587-040318 连接法兰组件 Flange subassembly 1 82459503
19 ▲225701587-040319 盖 Cover 1 82459502
20 ▲225701587-040320 轴承座 Bearing cage 1 75201767
21 ▲225701587-040321 主减速器壳体组 Carrier case 1 79800027
22 ▲225701587-040322 轴承 Bearing 1 54100015
23 ▲225701587-040323 调整垫片 Adjusting washers 1 79605013
24 ▲225701587-040324 螺栓M10X20 Bolt 2 50004003
25 ▲225701587-040325 锁紧片 Lock plate 2 75200054
26 ▲225701587-040326 轴承 Bearing 1 54100014
27 ▲225701587-040327 调整隔套 Adjusting sleeves 1 79605010
28 ▲225701587-040328 挡圈90 Circlip 1 52100012
29 ▲225701587-0405 差速器总成 Diff. assembly 1 82030502
30 ▲225701587-040330 锁紧片 Lock plate 1 79600097
