251808035 500FV.12.3 RIGHT DOOR

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲500D-070801 靠背骨架总成 seat back frame assy. 1 FS16D-04-1000
2 ▲500D-070802 座椅坐垫总成 Seat cushion assy. 1 FS16D-04-2000
3 ▲500D-070803 左操作调角器 Angle Adjuster (L) 1 FT166
4 ▲500D-070804 调角器塑料罩壳 Plastic Cover 1 FTK166
5 ▲500D-070805 带垫螺栓 Bolt with washer 3
6 ▲500D-070806 减震底框加高块连接组件 Shock-absorbing lower frame 1 FS16D-05-4200
7 ▲500D-070807 滑轨总成 Sliding track assembly 1 FS16D-04-3000
8 ▲500D-070808 塑手柄 Plastic lever 1 HBHC0008A0
9 ▲500D-070809 橡胶套 Rubber Sleeve 1
10 ▲500D-070810 减震上框 Shock-absorbing upper frame 1 FS16D-04-4100
11 ▲500D-070811 外撑杆组件 Outer Brace 1 HBJA0300B0
12 ▲500D-070812 内撑杆组件 Inner Brace 1 HBJA0200B0
13 ▲500D-070813 减震手轮 Shock-absorbing hand wheel 1 FJ05-40
14 ▲500D-070814 连杆板组件 Link Board Components 1 HBJA0600B0
15 ▲500D-070815 台阶板组件 Step Plate Assembly 1 HBJA0500B0
16 ▲500D-070816 调节螺杆 Adjusting Screw 1 FS16D-04-4302
17 ▲500D-070817 拉簧板 Spring board 2 HBJA0402B0
18 ▲500D-070818 减震拉簧 Shock-absorbing spring 2 FJ05-36
19 ▲500D-070819 阻尼簧 Damper 1 HBJA0013A0
20 ▲500D-070820 减震垫 Absorber 2 HBJA0005A0
21 ▲500D-070821 平面轴承 Plane Bearing 1 封闭8102型
22 ▲500D-070822 (Ø10X59)长销 Long pin 1 FJ02-05-01
23 ▲500D-070823 短销 Short pin 2 HBJA0410F0
24 ▲500D-070824 滑块 Sliding block 4 HBJA0003A3
25 ▲500D-070825 衬套1 Lining sleeve 4 HBJA0102A3
26 ▲500D-070826 阻尼簧连接螺栓 Damper bolt 2 HBJA0012F0
27 ▲500D-070827 F扣 F Buckle 28 HBJB0024A0
28 ▲500D-070828 轴承套 Bearing sleeve 1 FJ05-46
29 ▲500D-070829 定位轴 Fixing Shaft 1 HBJA0001E0
30 ▲500D-070830 台阶螺栓 Step Bolt 2 HBJA0006F0
31 ▲500D-070831 衬套2 Lining sleeve 2 1 HBJA0009A3
1 ▲801902762-01 靠背骨架总成 Frame Assembly 1 FS16D-04-1000
2 ▲801902762-02 座椅坐垫总成 Seat Assembly 1 FS16D-04-2000
3 ▲801902762-03 左操作调角器 Angle Adjuster 1 FT166
4 ▲801902762-04 调角器塑料罩壳 Plastic Casing 1 FTK166
5 ▲801902762-05 带垫螺栓 Bolt 3
6 ▲801902762-06 减震底框加高块连接组件 Heightening Block 1 FS16D-04-4200
7 ▲801902762-07 滑轨总成 Slide Assembly 1 FS16D-15-3000
8 ▲801902762-08 塑手柄 Handle 1 HBHC0008A0
9 ▲801902762-09 橡胶套 Rubber Sleeve 1
10 ▲801902762-10 减震上框 Up Frame 1 FS16D-15-4100
11 ▲801902762-11 外撑杆组件 Outside Brace 1 HBJA0300B0
12 ▲801902762-12 内撑杆组件 Inside Brace 1 HBJA0200B0
13 ▲801902762-13 减震手轮 Hand Wheel 1 FJ05-40
14 ▲801902762-14 连杆板组件 Link Board Components 1 HBJA0600B0
15 ▲801902762-15 台阶板组件 Step Plate Assembly 1 HBJA0500B0
16 ▲801902762-16 调节螺杆 Adjusting Screw 1 FS16D-04-4302
17 ▲801902762-17 拉簧板 Board 2 HBJA0402B0
18 ▲801902762-18 减震拉簧 Tension Spring 2 FJ05-36
19 ▲801902762-19 阻尼簧 Damper 1 HBJA0013A0
20 ▲801902762-20 减震垫 Absorber 2 HBJA0005A0
21 ▲801902762-21 平面轴承 Plain Bearing 1 封闭8102型
22 ▲801902762-22 (Ø10X59)长销 Pin 1 FJ02-05-01
23 ▲801902762-23 短销 Pin 2 HBJA0410F0
24 ▲801902762-24 滑块 Slider 4 HBJA0003A3
25 ▲801902762-25 衬套1 Sleeve 4 HBJA0102A3
26 ▲801902762-26 阻尼簧连接螺栓 Bolt 2 HBJA0012F0
27 ▲801902762-27 F扣 Buckle 28 HBJB0024A0
28 ▲801902762-28 轴承套 Bearing Bush 1 FJ05-46
29 ▲801902762-29 定位轴 Fix Shaft 1 HBJA0001E0
30 ▲801902762-30 台阶螺栓 Step Bolt 2 HBJA0006F0
31 ▲801902762-31 衬套2 Sleeve 1 HBJA0009A3
