Description
800152640 NBS510L LOCK XCMG
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 226802286 油位螺栓 Oil Lever Bolt 1
2 805300055 垫圈 30 WASHER 4 JB982-77
3 228700169 油塞 Oil Plug 4
4 803164073 油封B240X270X15D Oil Seal 1 GB9877.1-1988
5 805301374 垫圈 12(达克罗) Bolt 128
6 230500568 减振块 Shock absorber 16 YLJ-16C
7 227100467 压轮 DRUM 1
8 227001384 轴承盖 Bearing Cover 1
9 805000040 螺栓M16×60 Bolt 24 GB/T5783-2000
10 805301377 垫圈 16(达克罗) Wahser 64
11 228700189 左偏心轴 Eccentricity shaft 1
12 805000051 螺栓 M16×40 Bolt 24 GB/T5783-2000
13 228702923 轴承座 bearing housing 2
14 800511290 振动轴承 NJ324（NSK） Bearing 4
15 228700161 传动轴 Transmission shaft 1
16 228700192 右偏心轴 Right eccentricity shaft 1
17 228702219 右轴承座 Bearing housing right 2
18 228702220 框架轴承座 Frame bearing set 2
19 227001385 安装板 Mounting Plate 2
20 805000411 螺栓 M16×80 Bolt 16 GB/T5782-2000
21 805200210 螺母M16 Nut 16 GB/T6184-2000
22 228702222 马达连接盘 Motor bracket 1
23 805000032 螺栓M12X60 Bolt 144 GB/T5782-2000
24 805300018 垫圈12 washer 12 16 GB/T93-1987
25 805000404 螺栓M12X45 Bolt 8 GB/T5782-2000
26 228702218 锁片 Washer 8 GB/T93-1987
27 228702223 压板 Cover plate 1
28 805400068 挡圈32 Washer 1 GB/T893-1986
29 803164135 O型圈300×5.3 O-ring 2
30 805200098 螺母 M12 Nut 128 GB/T889.1-2000
31 228702217 花键套 Spline sleeve 1
32 800511395 框架轴承 HS723 Frame bearing set 2
33 801101753 油封280×320×20 Seal 2 GB/T13871
34 803164136 O型圈412×7 O-ring 2 GB/T3452.1-2005
35 228700157 橡胶套 Rubber sleeve 2
36 803201494 透气塞 breath cap 1 C-M12
37 801100339 油杯 M10×1 801100339 2 JB/T7940.2-1995
38 227001879 压板 1
39 805000716 螺栓M12X30 Bolt 9 GB/T5783-2000
40 228702284 3/4″堵头 plug 1
41 805300026 垫圈16 Washer 1
42 228700155 调整垫 Shim 4
43 805001910 螺栓M24×160 Bolt 24 GB/T5782-2000
44 805300021 垫圈24 Washer 32 GB/T97.1-2002
45 805200194 螺母 M24 Nut 24 GB/T 889.1-2000
46 805000384 螺栓M24×60 Bolt 8 GB/T5783-2000
47 227001378 减振器支座 Torque reducer support 4
48 226800413 凸块壳 Cam 3
49 805001990 螺栓M24×130 Bolt 18 GB/T5782-2000
50 805201509 螺母M24 Nut 18 GB/T6170-1987
51 805301386 垫圈22 Washer 18
1 800302218 轮胎23.5-25 TYRE 2
2 800305224 轮辋 Rim 2
3 ▲227001388-040103 球面螺母及螺栓 Spherical Nut 24
4 800305225 驱动桥 Drive axle 1
4 800352895 驱动桥 Drive axle 1
5 805001982 螺栓M20×280 Bolt M20×280 8 GB/T5783-2000
6 805300112 垫圈 20 Washer 20 8 GB/T97.1-2002
7 805200160 螺母 M20 10级 Nut 8 GB/T889.1-2000
8 805201527 螺母M14X1.5 Nut 4 GB/T889.2-2000
9 226800502 锁片 Lock plate 2
10 226800497 锁片 Lock plate 2
11 805002117 螺栓M14X1.5X45 Bolt 4 GB5785-2000
12 800511374 钢丝 Wire 4
13 226800237 螺钉 Screw 4
14 800352644 传动轴 TRANSMISSION SHAFT 1 XGC-02G
14 800302277 传动轴 Transmission Shaft Assembly 1
15 ▲227001388-040115 内胎 Inner Tyre 2
