Description
800511304 GB/T276-1994 BEARING 6210/N
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 803180246 液压油滤芯 Air filter elememt 1 SP-08X10
2 ▲800101726-040201 起动爪 Starting claw 1 KM186F-14008
3 ▲800101726-040401 柴油滤清器滤芯部件 Fuel filter elememt 1 KM186F-10300
4 ▲800101726-040301 机油滤清器滤芯部件 Oil filter elememt 1 KM186F-09200
1 231200299 上车架 Top Frame 1
2 231200309 防坠块 Anti-fall block 4
3 231200138 扎线板 Board 1
4 805300010 垫圈 8 Washer 11
5 805100125 螺钉 M8×20 Screw M8×20 2 GB/T65-2000
6 231200291 下车架 Down Frame 1
7 805000099 螺栓M12×60 Bolt 2 GB/T5783-2000
8 805300018 垫圈12 washer 12 10 GB/T93-1987
9 231200139 检修盖 Repair Cover 1
10 805000033 螺栓M8×16 Bolt 8 GB/T5783-2000
11 805100173 螺钉 M10×20 Screw M10×20 8 GB/T70.1-2008
12 805000048 螺栓M12X35 Bolt 4 GB/T5783-2000
13 231200140 减震块 Shock absorber 4
14 805200049 螺母 M12 Nut 6 GB/T6170-2000
15 231200141 左掩车体座 Left cover block 1
16 805000715 螺栓 M12×25 Bolt 4 GB/T 5783-2000
17 805000014 螺栓 Bolt 2
18 231200290 起吊架 Suspend Clamp 1
19 805000043 螺栓 M10×30 Bolt 2 GB/T 5783-2000
20 805300014 垫圈 10 Washer 2 GB/T93-1987
21 805200048 螺母 M10 Nut 3 GB/T6170-2000
22 231200142 斜拉杆 Rod 1
23 231200143 扶手销 Pin 1
24 801100336 黄油嘴M10X1 Grease Nipple 1 JB/T7940.1-1995
25 231200144 弹簧 Spring 1
26 805300113 垫圈12 Washer 1 GB/T96.1-2002
27 231200163 拉手 Handle 1
28 231200145 右掩车体座 Right cover block 1
29 805000714 螺栓 M10×20 Blot 1 GB/T5783-2000
30 231200259 压板 Plate 1
31 231200242 调整垫 Washer 2
32 231200252 调整垫 Washer 1
33 231200162 皮带轮 Belt roller 1
34 805701143 键C8X25 Key 1 GB/T1096-1979
35 231200146 透盖 Cover 1
36 231200147 防尘圈 Prevent dust cover 1
37 231200148 偏心轴 Eccentricity shaft 1
38 800511316 轴承6310-2RS Bearing 2 GB/T276-1994
39 231200149 闷盖 Cover 1
40 803164185 O型圈 O-ring 2 GB/T3452.1-2005
41 805000616 螺栓 M8×12 Bolt 1 GB/T5783-2000
42 805300069 垫圈 8 Washer 8 1
43 805400045 挡圈 110 RING 2 GB/T893.1-1986
44 231200190 锲块 Block 2
45 805000204 螺栓 M10×80 Bolt 1 GB/T5783-2000
46 231200258 隔尘板 Prevent dust cover 1
47 805200069 螺母 M12 Nut 1 GB/T 6172.1-2000
48 231200257 压板 Plate 2
49 839901557 塑料堵头 Plastic plug 4
50 231201450 护套 Jacket 1
51 231201451 护套 Jacket 1
