Description
803164008 JB/T8406-2001 HOSE B13×900
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲225701587-040601 第一轴 primary shaft 1 1701112-1103
2 ▲225701587-040602 卡环-固定第一轴轴承 check ring-to fix the primary shaft 1 1701117-950
3 ▲225701587-040603 轴用挡圈 shaft retaining ring 1 Q433160
4 ▲225701587-040604 圆柱滚子轴承 cylindrical roller bearing 1 NUP315ENR
5 ▲225701587-040605 隔环-固定圆柱滚子用 spacer ring- to fix the cylindrical roller 2 1701121-950
6 ▲225701587-040606 卡环-固定圆柱滚子用 check ring- to fix the cylindrical roller 1 1701126-950
7 ▲225701587-040607 圆柱滚子 cylindrical roller 19 1701122-950
8 ▲225701587-040608 圆柱滚子 cylindrical roller 19 1701123-950
9 ▲225701587-040609 圆柱滚子 cylindrical roller 19 1701124-950
1 ▲225701587-040701 离合器壳体 clutch case 1 1601011-1100
2 ▲225701587-040702 离合器通风孔盖板总成 clutch vent panel assembly 1 1601040-11
3 ▲225701587-040703 垫密片-通风孔盖板 washer-vent panel 1 1601041-11
4 ▲225701587-040704 螺栓-紧固通风孔盖板用 bolt-to fasten the vent panel 2 CQ1500616
5 ▲225701587-040705 分离叉轴与分离臂总成 clutch shifter and clutch release arm assembly 1 1602365-1136
6 ▲225701587-040706 分离叉轴-离合器 clutch shifter -clutch 1 1602367-1105
7 ▲225701587-040707 分离臂-分离叉轴 clutch release arm- clutch shifter 1 1602369-1109
8 ▲225701587-040708 弹性圆柱销-分离叉 elastic cylindricalpin-withdrawal fork 2 Q5280312
9 ▲225701587-040709 键-离合器分离叉 key- clutch withdrawal fork 1 Q5510832
10 ▲225701587-040710 衬套-离合器壳 bushing- clutch case 2 1601012-12
11 ▲225701587-040711 盖板-离合器壳检查孔 panel-clutch inspection cover 1 1601031-1100
12 ▲225701587-040712 螺栓-紧固检查孔盖板用 bolt- fasten the clutch inspection cover 2 CQ1500616
13 ▲225701587-040713 弹簧垫圈 spring washer 2 Q40306
14 ▲225701587-040714 螺栓-紧固离全器壳体用 bolt- fasten the clutch case 8 Q1601842
15 ▲225701587-040715 弹簧垫圈 spring washer 8 Q40318
16 ▲225701587-040716 分离叉-离合器 Withdrawal fork-clutch 1 1602366-680AG
17 ▲225701587-040717 螺栓-离合器分离叉 bolt-clutch withdrawal fork 1 1602371-680
18 ▲225701587-040718 弹簧垫圈 spring washer 1 Q40308
19 ▲225701587-040719 分离轴承座挡圈 shielding ring for release bearing 1 1602132-680
20 ▲225701587-040720 分离轴承-离合器 release bearing-clutch 1 996713
21 ▲225701587-040721 离合器分离轴承座总成 clutch release bearing assembly 1 1602130-660
22 ▲225701587-040722 分离轴承座注油管总成 release bearing oiling tube assembly 1 1602380-1100
