Description

803164243 EL10LOMD Joint 803162089

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 229600549 油箱 Oil box 1
2 229600909 垫 Washer 1
3 229600891 盖板 Cover board 1
4 800101718 空气滤清器 Breather filter 1
5 805000391 螺栓M8X16 Bolt 6
6 805300109 垫圈 5 Washer 6 GB/T93-1987
7 229600572 排油管 Pipe 1
8 229600554 油管接头 Adapter 1
9 805300026 垫圈16 Washer 2
10 227300286 接头 Joint 1
11 227300284 接头 Tie 1
12 229600552 输油管 Hose 1
13 859907948 喉箍 C10-16 Clamp 6
14 229600555 输油管 Hose 1
15 800101597 滤油器 Filter 1 发动机带
16 229600556 油管接头 Oil joint 1
17 803166709 垫圈8 Washer 2
18 229600551 胶垫 Veneer 1
19 805300069 垫圈 8 Washer 8 14
20 805000089 螺栓 M8X35 Bolt 14 GB/T 5783-2000
1 229600557 驱动盘 Drive plate 1
2 229600563 花键轴 Splined shaft 1
3 800511441 轴承6209 Bearing 3 GB/T276-1994
4 805000048 螺栓M12X35 Bolt 6 GB/T5783-2000
5 805300018 垫圈12 washer 12 6 GB/T93-1987
6 229600871 联接盘 Flywheel cover 1
7 801100112 O形密封圈115×3.55 O-ring 1 GB/T3452.1-1992
8 803164088 骨架油封 Seal B50X70X8F 1 GB/T9877.1-1988
9 227300278 磁性螺塞M20×1.5 Plug 1
10 229602057 驱动齿轮 Drive Gear 1 A
10 230501115 驱动齿轮 Driver gear 1 B
11 800500185 球轴承6210(50X90X20) Ball Bearing 3 GB／T276-94
12 229600561 螺塞 Plug 1
13 805300070 组合垫圈 48 4
14 229600870 分动箱体 Gearing box 1
15 229600568 堵 Plug 1
16 229600565 闷盖 Cover 1
17 227000277 输出齿轮 Output bear 2
17 229602056 输出齿轮 Output Gear 2 A
18 229600570 调整垫 Adjusting washer 2 B
19 801100082 O型密封圈 O-ringφ106×3.55 2 GB/T3452.1-1992
20 800901303 透气塞M12 Filter plug 1
21 229600560 轴承座 Bearing housing 1
22 229600569 轴承座 Bearing housing 1
23 805300014 垫圈 10 Washer 16 GB/T93-1987
24 805100036 内六角螺钉 M10×25 Screw 8 GB/T70.1-2000
25 805000714 螺栓 M10×20 Blot 8 GB/T5783-2000
26 229600566 调整垫 Adjuster 1
