803546484 QSDJZH066（R） Right Lamp Bracket

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 227001655 前梁 Front girder 1
1 227001672 前梁 Front girder 1 凸块轮
2 226802714 调整垫 Shim 2
3 226802715 调整垫 Shim 2
4 805002127 螺栓M24×2×120 Bolt 8 GB/T5785-2000
5 805300021 垫圈24 Washer 8 GB/T97.1-2002
6 227001657 压轮框架 Frame 1
6 227001673 压轮框架 Frame 1 凸块轮
7 805000008 螺栓 M6×12 Bolt 8 GB/T5783-2000
8 805300030 垫圈 6 Washer 6 8 GB/T93-1987
9 228700369 板 Board 2
10 228700370 盖 Cover 2
11 228700371 垫 Washer 6
12 805000616 螺栓 M8×12 Bolt 1 GB/T5783-2000
13 800511347 轴承 GAC85S/K Bearing 4 GB/T304-2002
14 228700391 转向铰接 Steering hitch 1
15 801100336 黄油嘴M10X1 Grease Nipple 3 JB/T7940.1-1995
16 228700372 盖 Cover 1
17 805101805 螺钉M12×16 Bolt 3 GB/T77-2000
18 228700373 V型圈 V-ring 2
19 805000560 螺栓M24×70 Bolt 12 GB/T5782-2000
20 228700374 调整垫 Shim 2
21 228700375 V型圈 V-ring 1
22 805000048 螺栓M12X35 Bolt 12 GB/T5783-2000
23 805300018 垫圈12 washer 12 12 GB/T93-1987
24 228700367 防尘盖 Prevent dust cover 1
25 228700703 刮泥板Ⅰ Scraper 2
26 228700704 刮泥板Ⅱ Scraper 2
27 805301377 垫圈 16(达克罗) Wahser 16
28 805000051 螺栓 M16×40 Bolt 16 GB/T5783-2000
29 228600280 可调刮齿 Scraper 18 凸块轮
30 228600281 固定板 Board 18 凸块轮
1 226802286 油位螺栓 Oil Lever Bolt 1
2 805300055 垫圈 30 WASHER 4 JB982-77
3 228700169 油塞 Oil Plug 4
4 803164073 油封B240X270X15D Oil Seal 1 GB9877.1-1988
5 805301374 垫圈 12(达克罗) Bolt 128
6 230500568 减振块 Shock absorber 16 YLJ-16C
7 228702284 3/4″堵头 plug 1
8 227001384 轴承盖 Bearing Cover 1
9 805000040 螺栓M16×60 Bolt 24 GB/T5783-2000
10 805301377 垫圈 16(达克罗) Wahser 16
11 227001542 左偏心块总成 Eccentricity Shaft 1
12 805000051 螺栓 M16×40 Bolt 24 GB/T5783-2000
13 227001992 轴承座 bearing housing 2
14 800553109 圆柱滚子轴承 NJ2324ME/C5S0 bearing 4
15 227001549 传动轴 Transmission shaft 1
16 227001550 右偏心块总成 Right eccentricity shaft 1
17 227002199 右轴承座 Bearing housing 2
18 228702220 框架轴承座 Frame bearing set 2
19 227001385 安装板 Mounting Plate 2
20 805000637 螺栓M16X85 Bolt 16 GB/T5782-2000
21 805200210 螺母M16 Nut 16 GB/T6184-2000
22 228702222 马达连接盘 Motor bracket 1
23 805046482 螺栓 M12×30(达克罗) Bolt 1
24 805300018 垫圈12 washer 12 16 GB/T93-1987
25 805046552 螺栓 M12×50 10.9(达克罗) Bolt 8 GB/T5783-2000
26 227002106 锁片 8
27 227002105 压板 1
28 803164135 O型圈300×5.3 O-ring 2
29 805701064 键14×9×63 Ring 1 GB1096-79
30 805000032 螺栓M12X60 Bolt 144 GB/T5782-2000
31 805200098 螺母 M12 Nut 152 GB/T889.1-2000
32 227001556 套 sleev 1
33 800511395 框架轴承 HS723 Frame bearing set 2
34 801101753 油封280×320×20 Seal 2 GB/T13871
35 803164136 O型圈412×7 O-ring 2 GB/T3452.1-2005
36 227001554 橡胶套 Rubber sleeve 2
37 803201494 透气塞 breath cap 1 C-M12
38 801100339 油杯 M10×1 801100339 2 JB/T7940.2-1995
39 227001879 压板 1
40 805006287 螺栓 M12×40(达克罗) bolt 8 GB/T5783-2000
41 805338246 垫圈16 washer 48 Nord-Lock
42 227002069 压轮 1
44 228700155 调整垫 Shim 4
45 805001910 螺栓M24×160 Bolt 24 GB/T5782-2000
46 805300021 垫圈24 Washer 32 GB/T97.1-2002
47 805200235 螺母 M24 Nut 24 GB/T6184-2000
48 227001378 减振器支座 Torque reducer support 4
49 805000384 螺栓M24×60 Bolt 8 GB/T5783-2000
50 805300026 垫圈16 Washer 1
51 800306651 弹性联轴器 Stretch connect 1 ROTEX 48-521553-2
