Description

275300202 WA1210.1.2 RIM BOLT

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 228300101 压轮 Drum 1
2 805000014 螺栓 Bolt 80
3 805301374 垫圈 12(达克罗) Bolt 80
4 805200098 螺母 M12 Nut 90 GB/T889.1-2000
5 805000727 螺栓M10X25 Bolt 6 GB/T5783-2000
6 805000051 螺栓 M16×40 Bolt 17 GB/T5783-2000
7 239900236 透气螺栓 Breath cap 1
8 228100111 支撑板 Bracket 1
9 800302366 减速机 CW18A11HB4051 Rim decelerator 1
10 228300167 驱动板 Drive plate 1
11 805001989 螺栓M24×110 Bolt 4 GB/T5782-2000
12 805300010 垫圈 8 Washer 8
13 805300018 垫圈12 washer 12 14 GB/T93-1987
14 805000032 螺栓M12X60 Bolt 4 GB/T5782-2000
15 805100154 螺栓M8X30 Bolt 8
16 805000061 螺栓 M16×65 Bolt 8 GB/T5782-2000
17 805300013 垫圈16 Washer 8 GB/T 97.1-2002
18 227300174 安装板 Mounting plate 1
19 227300173 轴承座 Bearing seat 1
20 805300011 垫圈 16 Washer 65 GB/T 93-1987
21 805200051 螺母 M16 Nut 8 GB/T6170-2000
22 805000026 螺栓 M16×45 Bolt 40 GB/T 5783-2000
23 803164066 O型圈 390×8.6 O-ring 2 GB1235-76
24 227300346 外轴承座 Outer bearing seat 1
25 800511396 振动轴承 Drum bearing 4 NJ322
26 228300105 左偏心轴 Left eccentric shaft 1
27 805300014 垫圈 10 Washer 6 GB/T93-1987
28 805000101 螺栓 M24×100 Bolt 4 GB/T5782-2000
29 227300347 轴承座 Inner bearing seat 2
30 227300456 视油螺塞 Oil lever glass 1
31 227300175 橡胶套 Rubber sleeve 2
32 230200763 联接圈 Motor bracket 1
33 227300365 外轴承座 Outer bearing seat 1
34 803166349 骨架油封HNBR Oil seal 1
35 805300021 垫圈24 Washer 20 GB/T97.1-2002
36 805200194 螺母 M24 Nut 8 GB/T 889.1-2000
37 228300104 右偏心轴 Right eccentric shaft 1
38 801902916 减震器 Shock absorber 10
39 800511397 框架轴承 bearing 1 JM822049-90N01
40 227300172 轴承压盖 Bearing cover 1
41 227300364 轴承座盖 Bearing cover 1
42 228100112 右连接板 Right connection plate 1
43 227300377 传动轴 Drive shaft 1
44 228700169 油塞 Oil Plug 1
45 805300055 垫圈 30 WASHER 2 JB982-77
46 227300374 压轮垫片δ1 0.19kg Shim 4
47 227300375 压轮垫片δ2 0.39kg Shim 8
48 227300376 压轮垫片δ5 0.915kg Shim 12
50 800302482 球面螺母M22×1.5 Spherical Nut 1
51 227300378 花键套 Spline sleeve 1
