Description
803074999 502-7185-831-2204 Steering XT870 PARTS XCMG
序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 XGZY01-V-01 靠背骨架总成 Frame Assembly 1 FS16D-04-1000 FS16D-04-1000
2 XGZY01-V-02 座椅坐垫总成 Seat Assembly 1 FS16D-04-2000 FS16D-04-2000
3 XGZY01-V-03 左操作调角器 Angle Adjuster 1 FT166 FT166
4 XGZY01-V-04 调角器塑料罩壳 Plastic Casing 1 FTK166 FTK166
5 XGZY01-V-05 带垫螺栓 Bolt 3
6 XGZY01-V-06 减震底框加高块连接组件 Heightening Block 1 FS16D-04-4200 FS16D-04-4200
7 XGZY01-V-07 滑轨总成 Slide Assembly 1 FS16D-15-3000 FS16D-15-3000
8 XGZY01-V-08 塑手柄 Handle 1 HBHC0008A0 HBHC0008A0
9 XGZY01-V-09 橡胶套 Rubber Sleeve 1
10 XGZY01-V-10 减震上框 Up Frame 1 FS16D-15-4100 FS16D-15-4100
11 XGZY01-V-11 外撑杆组件 Outside Brace 1 HBJA0300B0 HBJA0300B0
12 XGZY01-V-12 内撑杆组件 Inside Brace 1 HBJA0200B0 HBJA0200B0
13 XGZY01-V-13 减震手轮 Hand Wheel 1 FJ05-40 FJ05-40
14 XGZY01-V-14 连杆板组件 Link Board Components 1 HBJA0600B0 HBJA0600B0
15 XGZY01-V-15 台阶板组件 Step Plate Assembly 1 HBJA0500B0 HBJA0500B0
16 XGZY01-V-16 调节螺杆 Adjusting Screw 1 FS16D-04-4302 FS16D-04-4302
17 XGZY01-V-17 拉簧板 Board 2 HBJA0402B0 HBJA0402B0
18 XGZY01-V-18 减震拉簧 Tension Spring 2 FJ05-36 FJ05-36
19 XGZY01-V-19 阻尼簧 Damper 1 HBJA0013A0 HBJA0013A0
20 XGZY01-V-20 减震垫 Absorber 2 HBJA0005A0 HBJA0005A0
21 XGZY01-V-21 平面轴承 Plain Bearing 1 封闭8102型 封闭8102型
22 XGZY01-V-22 (Ø10X59)长销 Pin 1 FJ02-05-01 FJ02-05-01
23 XGZY01-V-23 短销 Pin 2 HBJA0410F0 HBJA0410F0
24 XGZY01-V-24 滑块 Slider 4 HBJA0003A3 HBJA0003A3
25 XGZY01-V-25 衬套1 Sleeve 4 HBJA0102A3 HBJA0102A3
26 XGZY01-V-26 阻尼簧连接螺栓 Bolt 2 HBJA0012F0 HBJA0012F0
27 XGZY01-V-27 F扣 Buckle 28 HBJB0024A0 HBJB0024A0
28 XGZY01-V-28 轴承套 Bearing Bush 1 FJ05-46 FJ05-46
29 XGZY01-V-29 定位轴 Fix Shaft 1 HBJA0001E0 HBJA0001E0
30 XGZY01-V-30 台阶螺栓 Step Bolt 2 HBJA0006F0 HBJA0006F0
31 XGZY01-V-31 衬套2 Sleeve 1 HBJA0009A3 HBJA0009A3
1 XGZY03-A-01 靠海绵 Backrest sponge 1 K03 K03
2 XGZY03-A-02 座垫海绵 Seat sponge 1 Z03 Z03
3 XGZY03-A-03 左操作调角器 Left angle adjuster 1 丰田166角调 丰田166角调
4 XGZY03-A-04 角器塑料卡罩 Cover 1 丰田166卡罩 丰田166卡罩
5 XGZY03-A-05 带垫螺栓 Bolt with washer 3
6 XGZY03-A-06 橡胶套 Rubber wrap 1 FS11-08-03 FS11-08-03
7 XGZY03-A-07 上框焊接总成 Up frame 0 FS11-0100 FS11-0100
8 XGZY03-A-08 中框焊接总成 Middle frame 0 FS11-0200 FS11-0200
9 XGZY03-A-09 底框焊接总成 Base frame 0 FS11-0300 FS11-0300
10 XGZY03-A-10 大底板 Big plate 1 FS16G-80000 FS16G-80000
11 XGZY03-A-11 升降总成 Lift framework 1 FS11-0400 FS11-0400
12 XGZY03-A-12 滑轨总成 Guide track 1 FS16G-70000 FS16G-70000
13 XGZY03-A-13 外撑杆焊接总成 Outer support 1
14 XGZY03-A-14 内撑杆焊接总成 Inner support 1
15 XGZY03-A-15 齿板 Teeth board 2 HBSA0007E0 HBSA0007E0
16 XGZY03-A-16 手柄 Handle 0 FS11-07-12 FS11-07-12
17 XGZY03-A-17 齿头 2 HBSA0008E0 HBSA0008E0
18 XGZY03-A-18 滑头 2 HBSA0009E0 HBSA0009E0
19 XGZY03-A-19 手柄扭簧 Handle spring 2 HBSA0010E0 HBSA0010E0
20 XGZY03-A-20 扭簧 Spring 3 FS-06-10 FS-06-10
21 XGZY03-A-21 扭簧 Spring 1 FS-06-09 FS-06-09
22 XGZY03-A-22 φ12X28短销 Short pin 4 HBSA0011E0 HBSA0011E0
23 XGZY03-A-23 台阶螺栓 Bolt 4 HBSA0012E0 HBSA0012E0
24 XGZY03-A-24 调节组件 Adjuster assembly 1
25 XGZY03-A-25 反向调节手轮 Reverse adjuster 1 FS16 FS16
26 XGZY03-A-26 升降塑手柄 Lift handle 2 HBSA0016A2 HBSA0016A2
27 XGZY03-A-27 F扣 F lock 28 HBJB0024A0 HBJB0024A0
28 XGZY03-A-28 阻尼簧 Damp spring 1 FS16-06-08 FS16-06-08
29 XGZY03-A-29 滑块 Slip block 4 FS11-08-06 FS11-08-06
30 XGZY03-A-30 轴销2 Pin 2 FS11-07-08 FS11-07-08
31 XGZY03-A-31 调节螺杆 Adjust screw 1 FS11-06-02 FS11-06-02
32 XGZY03-A-32 拉簧杆 Spring pole 2 HBJA0402B0 HBJA0402B0
33 XGZY03-A-33 11圈拉簧 Spring 2 FJ05-36 FJ05-36
34 XGZY03-A-34 长台阶螺栓 Bolt 2 FJ02-05-05 FJ02-05-05
35 XGZY03-A-35 φ10×39长销 Long pin 1 FS11-07-11 FS11-07-11
36 XGZY03-A-36 平面轴承 Bearing 1 8102型 8102型
37 XGZY03-A-37 M10螺母（无牙） Nut 4
38 XGZY03-A-38 M8X25内六角螺栓 Bolt 4
39 XGZY03-A-39 M8X16内六角螺栓 Bolt 4
40 XGZY03-A-40 M8防松螺母 Lock nut 4
1 500FN.10.2-1 前下包 Shell 1 RC1400-01 RC1400-01
2 500FN.10.2-2 仪表上盖 Cover 1 RC1400-02 RC1400-02
3 500FN.10.2-3 左大包 Shell 1 RC1400-03 RC1400-03
4 500FN.10.2-4 软轴 Flex Shaft 1 L1334×1950 L1334×1950
5 500FN.10.2-5 方向盘 Steering Wheel 1 RC1400-04 RC1400-04
6 500FN.10.2-6 龙马开关 Switch 1 NY-LJ NY-LJ
7 500FN.10.2-7 右大包 Shell 1 RC1400-05 RC1400-05
8 500FN.10.2-8 调节手柄 Handle 1 RC1400-06 RC1400-06
9 500FN.10.2-9 翘板开关盒 Switch Control Box 1 RC1400-07 RC1400-07
10 500FN.10.2-10 开关盒下盖 Cover 1 RC1400-08 RC1400-08
11 500FN.10.2-11 后下包 Shell 1 RC1400-09 RC1400-09
12 500FN.10.2-12 方向机支架 Bracket 1 RC3400-1010 RC3400-1010
