803644247 JK231 brake lamp switch

序号 零件号 版本 中文名称 英文名称 数量 备注 装配备注
1 ▲225700940-0101 右轴装配 Right shaft assembly 1
2 ▲225700940-0102 右盖板 Right cover plate 1
3 805000008 螺栓 M6×12 Bolt 24 GB/T5783-2000
4 805300030 垫圈 6 Washer 6 24 GB/T93-1987
5 ▲225700940-0103 仪表箱体 Meter box shell 1
6 ▲225700940-0104 中轴装配 Middle shaft assembly 1
7 ▲225700940-0105 左轴装配 Left shaft assembly 1
8 ▲225700940-0106 左侧板 Nearside plate 1
9 805000727 螺栓M10X25 Bolt 4 GB/T5783-2000
10 805300014 垫圈 10 Washer 4 GB/T93-1987
11 805300017 垫圈10 Washer 4 GB/T97.1-2002
12 805300029 垫圈 6 Washer 6 8 GB/T97.1-2002
13 ▲225700940-0107 左护套 Left jacket 1
14 ▲225700940-0108 壳体 Shell 1
15 ▲225700940-0109 右护套 Right jacket 1
16 ▲225700940-0110 右侧板 Starboard plate 1
17 ▲225700940-0111 左盖板 Left cover plate 1
1 ▲225700940-0201 方向盘 Steering wheel 2
2 ▲225700940-0202 防尘盖 Dust proof cover 2
3 ▲225700940-0203 铜套 Cupreous sheath 4
4 805101728 螺钉 M5×5 Bolt M5×5 11 GB/T65-2000
5 ▲225700940-0204 支座I Seat I 2
6 805000714 螺栓 M10×20 Blot 36 GB/T5783-2000
7 805300014 垫圈 10 Washer 36 GB/T93-1987
8 ▲225700940-0205 轴I Shaft I 2
9 ▲225700940-0206 键　5X20 Key 7
10 ▲225700940-0207 轴承I Bearing I 6
11 ▲225700940-0208 挡圈　22 Circlip 5
12 ▲225700940-0209 挡圈　36 Circlip 6
13 ▲225700940-0210 齿轮 Gear 7
14 ▲225700940-0211 轴承II Bearing II 2
15 ▲225700940-0212 右支座 Right seat 1
16 ▲225700940-0213 左支座 Left seat 1
17 ▲225700940-0214 轴II Shaft II 1
18 ▲225700940-0215 支座II Seat II 2
19 ▲225700940-0216 轴承下座 Bearing seat down 2
20 ▲225700940-0217 轴承上座 Bearing seat up 2
21 805300109 垫圈 5 Washer 4 GB/T93-1987
22 805000010 螺栓M5×20 Bolt 4
23 805300017 垫圈10 Washer 4 GB/T97.1-2002
24 ▲225700940-0218 轴承III Bearing III 2
25 ▲225700940-0219 轴III Bearing III 1
26 ▲225700940-0220 轴IIII Bearing IIII 1
27 ▲225700940-0221 下支座 Seat down 1
